Project Kickoff

2026-03-28


Goal

Build a system able to:

  • listen continuously
  • detect a wake word
  • record a voice command
  • understand the intent
  • trigger an action
  • respond with sound or voice

All of it locally, with no cloud dependency.

Overall Architecture

The system is split into several blocks:

Microphone
→ Wake word
→ Recording
→ Speech-to-Text (Whisper)
→ Interpretation (LLM)
→ Action
→ Response (sounds / TTS / LEDs)

Each block will be explored and validated separately.

1. Audio and Hardware

The project relies on:

  • Raspberry Pi (Debian Bookworm)
  • Adafruit Voice Bonnet (microphones + LEDs + speakers)
  • audio output tested with pink noise

Important points:

  • correctly identify the right audio device
  • properly handle simultaneous input/output
  • implement clean LED management (cleanup)

2. Wake Word: the First Challenge

❌ Picovoice (Porcupine)

Initially considered, but dropped:

  • now requires a pro account
  • external dependency
  • less suitable for a long-term personal project

✅ openWakeWord

Chosen solution:

  • open source
  • runs locally
  • based on TFLite models

Issues encountered:

  • missing models → download_models()
  • NumPy / SciPy conflicts → downgrade and version alignment
  • false positives → filtering required

Solutions implemented:

  • high threshold (~0.95)
  • several consecutive frames
  • refractory period (10s)
  • stop audio stream during actions

👉 Key takeaway: a wake word is not reliable “raw” — it needs control logic

3. Classic Problem: the Robot Triggers Itself

Robie was detecting its own audio output (feedback loop).

Solution:

  • pause listening during:
    • recording
    • sound response
  • add a grace delay

4. STT ≠ Understanding

Testing faster-whisper

5. Introducing a Local LLM

Test with Ollama + Qwen2.5 (1.5B)

Result:

  • ~2 second latency
  • stable behavior
  • viable for embedded usage

👉 Conclusion: a small local LLM on Raspberry Pi is usable

The Key Metric: Latency

What matters is not total speed, but the time before the response starts.

  • < 3 seconds : good
  • 3–6 : acceptable
  • > 6 : frustrating

UX trick:

  • yellow LED = “thinking”
  • intermediate sound cue

👉 turns lag into natural behavior

6. Role of the LLM in Robie

The LLM should not be used for open-ended chatting.

It will be used to:

  • transform a sentence into an intent
  • structure the command

Example:

Input:

“Robie, note that Thomas needs to bring his coat tomorrow”

Output:

{
  "intent": "take_note",
  "content": "Thomas needs to bring his coat tomorrow",
  "answer": "Noted."
}

The Python code then executes the action.

7. French Language Support

Important constraint: French-speaking children.

Solutions:

  • multilingual Whisper (not .en)
  • language forced to fr
  • multilingual LLM (Qwen works well)
  • prompts in French
  • intents in French

⚠️ Note: children’s voices are harder to recognize → tolerance will be needed.

8. What About My Coral TPU?

Not usable for LLMs.

Why:

  • Coral = quantized TFLite models
  • LLM = incompatible architecture

Relevant future uses:

  • vision (camera)
  • object detection
  • environmental perception

Conclusion

This first session shows that building a local embedded assistant is probably achievable. Next step: finish testing each block, then start designing the overall architecture for version 2.

V1

Component testing and performance stability

V2

Pipeline construction and first real-world tests
